To be used with Amana #61335 IN-SAND™ Dynamically Balanced Non-Random Orbital CNC Sander with 3.5mm Orbital Stroke and 3/4" Shank
WARNING! The max RPM for the 61335 Dynamically Balanced non Random Orbital Sander is 8,000. Working with higher rotation speed can cause damage to the machine spindle.
Please note: After one hour of sanding, stop and turn the power off on your CNC machine. Inspect to ensure the tool spins freely. Repeat after each hour of sanding.
Designed for CNC Sanding: Wood and Resin.
Consistent Surface Quality
Delivers uniform sanding results and smooth, repeatable finishes directly from your CNC.
Hands-Free Operation
Eliminates much of the manual sanding to remove tool marks, saving time while improving surface prep.
Efficient Dust Collection
Connects to your CNC’s dust collection system, reducing airborne dust and exposure.
Minimal Material Handling
Surfacing, milling, and sanding in one setup for faster, more accurate results.
Finish-Ready Prep
Leaves a clean, even surface ready for final sanding with a random-orbit sander.
Recommended running parameters (depending on application)
- 4,000 – 7,000 RPM
- 40 – 800 IPM (1,016 – 20,320 mm/min)
UNDERSTANDING THE SANDER BEFORE USE:
The In-Sand™ is a non-random orbital sander, which operates in a fixed, predictable motion. It is designed for CNC sanding wood and resin.
The sander should not be used to flatten uneven surfaces, the surface must already be flat before sanding.
The sander is dynamically balanced from the factory using the counterbalance screw as the balancing element.
DO NOT ADJUST SCREW Please ensure the red mark is aligned on screw head to tool body.
If the red mark on counterbalance screw is not aligned properly to the red mark on the tool body, please email our technical support team for assistance at customerservice@amanatool.com.
NOTE: After one hour of sanding, stop and turn the power off on your CNC machine. Inspect to ensure the tool spins freely and the sanding pad is in good condition. Repeat after each hour of sanding.
Heavy Duty Spring, Pre-Installed
Your sander is designed as heavy-duty tool built for demanding machines and applications. Each unit is equipped with a single spring system, allowing you to control sanding intensity by adjusting the Z-axis pressure. Apply more pressure for rough sanding or lighten the pressure for finer finishing, giving you full control over surface quality and material removal.
